2 PCS Flange Floating Ball Valve
  • 2 PCS Flange Floating Ball Valve2 PCS Flange Floating Ball Valve
  • 2 PCS Flange Floating Ball Valve2 PCS Flange Floating Ball Valve

2 PCS Flange Floating Ball Valve

Waits Valve's 2 PCS Flange Floating Ball Valve ‌complies with API 608 and ISO 17292 standards. It also adopts lever operation, easy operation, and has safety designs such as anti static valve stem, suitable for petrochemical, natural gas and power industries. Its floating ball structure presses the valve seat under fluid pressure to achieve tight closure, suitable for on-off control of various pipelines.

Send Inquiry

Product Description

Waits Valve high quality 2 PCS Flange Floating Ball Valve ‌With a compact two-piece design and flanged connections, you will find that installation is easy when you purchase our valves. Connecting the stem directly to the ball makes it easier to control the release/stop of the fluid. Because the ball is not fixed to the valve body, it is called a floating ball valve. Instead, the ball is supported by the upstream and downstream seats and can flow freely within the valve body to a certain extent.
2 PCS Flange Floating Ball ValveWhen the ball is in the closed position, the fluid pressure forces the ball against the downstream seat, forming a tight seal to prevent leakage. You need to understand this principle to make better use of this product. Floating ball valves usually consist of a one-piece or two-piece valve body with a ball with holes inside the valve body. However, when the fluid pressure is low or the valve seat is worn, the valve cannot seal effectively. This valve usually has flanged inlets and outlets to facilitate installation into the pipeline system. We use precision forged two-piece carbon steel/stainless steel/alloy steel valve bodies with both floating balls and PTFE seats for low torque operation and bidirectional flow, suitable for industrial fluid systems.


Implementation Standards-2 PCS Flange Floating Ball Valve
Design Standards API 6D, API 608, BS5351
Flange Standard ASME B16.5/ASME B16.47- A/B / EN1092-1/2
Connection RTJ, RF, FF
Test Acceptance API 598 EN12266
Structure Length API6D, ASME B16.10, EN588
Pressure and Temperature Ratings ASME B16.34
Fire Test API 6FA API 607
Low Leakage Standard ISO 15848-1, API 622
Anti-Corrosion Design NACE MR 0175


Application-2 PCS Flange Floating Ball Valve
Size NPS 1/2″~ NPS 12″ DN15~ DN300
Pressure Range CL150~CL600 PN20 ~ PN100
Temperature Range -20℃~180℃
Application Water, oil, gas and other non-corrosive neutral media.
Drive Mode Handle
Valve Body/Valve Cover Forgings: A105, A182 F304, F304L, F316, F316L, F51, F53, B148, A350 LF2, LF3, LF5
Castings: A216 WCB, CF3, CF8, CF3M, CF8M, 4A, 5A, C95800, LCB, LCC, LC2
Valve Core/Internal Parts Forgings: A105, A182 F304, F304L, F316, F316L, F51, F53, B148, A350 LF2, LF3, LF5, Monel
Valve Seat PTFE, RPTFE, NBR, EPDM.F304.F316.STL
Valve Stem A182-F6a-F304-F316-F51 17-4PH/XM-19 ...


Product Features
Waits Valve 2 PCS Flange Floating Ball Valve adopts a floating ball design. Under the action of fluid pressure, the ball is close to the valve seat, which can bring good sealing effect.
The valve adopts a two-piece flange structure, which is easy to install and maintain, and can be quickly disassembled for internal inspection and repair.
The streamlined ball and stem design give the valve low torque operation, which can help you achieve precise switching control even in high-pressure applications. Its full-bore or reduced-bore flow path can minimize fluid resistance and is suitable for handling a variety of media, including corrosive fluids, gases and slurries.
In addition, the Waits valve is designed for bidirectional flow, has versatility in pipeline systems, and is equipped with anti-static and fire-proof functions to meet safety standards in industrial environments.

2 Pcs Flange Floating Ball Valve2 Pcs Flange Floating Ball Valve
